MightyMount Wall Arm Mounting

MightyMount

Strongarm Healthcare’s MightyMount keyboard and monitor wall arm defines a category of its own and stands apart from common “computer store grade” keyboard and display arm mountings. MightyMount’s dual-axis pivot points and vertical articulation allow the monitor and keyboard to be quickly and easily repositioned to achieve optimal ergonomics for each user. Simplified functionality makes MightyMount favored among hospital and point-of-care users. The robust, die-cast aluminum construction makes it a superb choice for any healthcare environment.

Features

  • Integrated cable management
  • Repositions effortlessly with 100% counter-balanced adjustability
  • 12″ of vertical articulation (16″ with the MightyMount XR)
  • Remains level throughout vertical and horizontal movement
  • Secure mechanical lock-in-place feature
  • A variety of keyboard enclosures, trays, and work surfaces available
  • All trays and work surfaces include a USB powered USB 3.0 hub (powered USB hub optional)
  • Dual-axis pivot action
  • Tilting display mount with standard VESA bracket
  • Robust cast aluminum construction, antimicrobial powder-coated finish (see color options)
  • Fully extends 34.75″ horizontally from mounting point, up to 52.75″ with optional horizontal extension*
  • Folds to 7″ depth for convenient stowaway
  • Mounting tracks available from 12″ to 72″
  • Limited Lifetime Warranty

*Measured from mounting point with keyboard tray fully extended from the keyboard enclosure.

Strongarm Healthcare MightyMount Wall Arm

Optional: The MightyMount XR increases the vertical articulation to 16″ and increases the maximum horizontal extension from mounting point to 37.75″ (55.75″ with optional horizontal extension arm). Additionally, the optional MightyMount PatientView™ feature provides the ability to pivot the display and keyboard independently, allowing the patient to view the information displayed on the screen.

Video: Articulation & Ergonomics

Specifications

Adjustability Vertical Travel 12″ with MightyMount
16″ with MightyMount XR
Swivel at Display End 340°
Swivel at Mounting End 180°
Display Tilt Forward tilt: 15°
Backward tilt: 45°
Vertical Positioning Counterbalanced vertical adjustability
Display and keyboard maintain level when repositioned
Materials of Construction Body 319F cast aluminum alloy
Keyboard Tray 5052 aluminum alloy
Cable Management Integrated internal/external cable covers
Bearings Horizontal Axles Precision ground ball bearings
Vertical Axles Acetal bushings
Mounting Styles Track mount, wall mount, or surface mount options available.
Finish 2-part catalyzed polyurethane antimicrobial powder coat and custom colors available
Approvals and Certifications UL, CE, U.S. GSA Advantage, OSHPD
Strongarm Healthcare Wall Arm Ratings and Certifications

Keyboard Options

MightyMount is available with a variety of keyboard and mouse tray options. All keyboard enclosures and trays include a USB-powered USB 3.0 hub (powered USB hub optional). Custom keyboard tray and work surface configurations are available.

Standard Slideout Keyboard Module
(18.5″ width)

Wide Slideout Keyboard Module
(22.5″ width)

Standard Slideout Keyboard Module
(with slideout mouse trays)

Wide Slideout Keyboard Module
(with slideout mouse trays)

Open Keyboard & Mouse Tray

Accessories

Strongarm Healthcare offers a wide selection of optional CleanMount accessories that are either track-mounted or secured with custom VESA-mounted brackets. Accessories include PC holders and enclosures, dual display mountings, brackets for bar code scanners and card readers, horizontal extension arms, webcams, and more.

Color Options

Strongarm Wall Arm Mount Color Options

All Strongarm Healthcare products are available in a variety of stock antimicrobial RAL CLASSIC powder coat colors. Additional non-stock color options and custom colors are available upon request at an additional cost.

Customized Solutions

Strongarm Healthcare Customized Wall Arm Mounts and Workstation Systems

Strongarm Healthcare has the expertise and experience to customize, design, and build your healthcare application’s ideal solution. Our extensive design resources enable us to engineer every feature you’ll need before in-house fabrication, assembly, finishing, testing, quality assurance, and on-time delivery. Since 1990, we’ve designed, built, and delivered over 400,000 products with more than 310,000 different design customizations for our customers.
